This mirror is primarily crafted from die-cast aluminum (ADC12)material, ensuring exceptional heat dissipation while allowing for a variety of color surface treatments. The luminous components consist of a PC lens and PC reflector, accompanied by a transparent glass lamp shade that emits a gentle and soothing illumination. With an IP54 waterproof rating, this exquisite lamp is highly suitable for bars, dressing tables, and other similar application areas.
Application Areas: It's widely used in bathrooms, dressing tables, and bedside occasions from hotels, restaurants, home, etc.
| Code | ML42-70-8W-D | ML42-70-10W |
|---|---|---|
| Dimension(mm) | 247*70*90 | |
| Watt(W) | 8W | 10W |
| Rated Input Voltage | AC220-240V | |
| Input Voltage | AC198-264V | |
| Light Source | COB | |
| SDCM | <6 | |
| CCT(K) | 1-CCT:2700K/3000K/4000K/5000K||3-CCT:3000K+4000K+5000K | |
| CCT Selection DIP Switch | YES | |
| DIM 1-CCT umingus Flux (lm)±5% CRI80 | 820-950 | |
| 1-CCT umingus Flux (lm)±5% CRI80 | 570-770 | |
| NO-DIM 3-CCT umingus Flux (lm)±5% CRI80 | 550-700 | |
| DIM 3-CCT umingus Flux (lm)±5% CRI80 | 380-550 | |
| CRI | 1-CCT:80/3-CCT:90 | |
| Beam Angle (°) | 40° | |
| LED Driver | Driver built-in | |
| Dimming Option | Triac | |
| Electrical Class | Class | |
| Ingress Protection(IP Rating) | IP54 | |
| Product Finishing | White RAL9016/Chrome RAL7045 | |
| Optics Material | PC | |
| Housing Material | Aluminum | |
| Lifetime (hr) | 50,000H | |
| Glow wire test (℃) | 750℃ | |
| Operating Temp.(℃) | -20℃~45℃ | |
| Storage Temp.(℃) | -20℃~65℃ | |
| Installation | Wall mount | |
